Description
Lake People DIGI-TOOL F612
The Lake People DIGI-TOOL F612 is an AES/EBU Splitter with 2 modules - the first featuring 1 input and 4 outputs, and the second featuring 1 input and 8 outputs.
Inputs and outputs are transformer balanced, with impedance 110 ohms via XLR sockets according to AES 3/11.
The highly sensitive inputs regenerate improper or weak input signals, whilst the high output voltages are able to drive AES3 signals over long distances.
The Lake People DIGI-TOOL F612 offers failsafe operation through switchable Auto-Mode Multimode power supply 90 … 260V AC.
MODULE 1 (AES/EBU Splitter)
- 1 input, 4 outputs via XLR sockets, transformer balanced, impedance 110 ohms, according to AES 3/11
- High sensitive inputs to regenerate unproper or weak input signals
- High output voltages (> 4 Veff) to drive long distances
MODULE 2 (WCLK/AES-id Splitter)
- 1 input and 8 outputs via BNC sockets, unbalanced, impedance 75 ohms
- High sensitive inputs to regenerate unproper or weak input signals
- High output voltages to drive long distances
- Jumpers to switch the output impedance from 75 ohms to 50 ohms to drive improper WCLK inputs
- Jumpers to switch to AES-3id operation
- Jumpers to switch to “Superclock 256 Fs”
- Failsafe operation through switchable Auto-Mode Multimode power supply 90 … 260V AC
MULTI-SYNC UNIT OPTION:
The MULTI-SYNC UNIT option offers the following features:
- 3 external inputs, sample rate 28 ... 210 kHz, AES/EBU, AES-id, WCLK - 1 AES-EBU sync output
- Internal oscillators with 32, 44.1, 48, 88.2, 96, 176.4, 192 kHz
- Auto-Mode, Format, Key-Lock und Mute switchable
- Displays for: Sync-Source, Sample-Rate, Lock, Error, Mute, Pro/Con- Format, Auto-Mode, Key-Lock
Specifications
Item | Details |
---|---|
Item number | 1006252 |
Dimensions | 483 x 44 x 166 mm (W x H x D) |
AES/EBU I/O | 2 / 8 (XLR) |
Bit depth | 24 Bit |
Output impedance | 110 Ohm |
Input sensitivity | < 200 mV |
Input impedance | 110 Ohm |
Additional features | Optional multi-sync option available |
Housing | 19" / 1 HE |
Sample rate | Max. 192 kHz |
Power supply | Internal 230 V / 115 V AC |
SPDIF I/O | 1 / 8 (BNC) |
